Application
-
The general purpose ultrasonic level transmitter provides continuous level measurement up to 18.0’ (5.5m) with a 4-20 mA signal output, and is configured via our free Webcal software. The level sensor has 4 programmable relays with selectable hysteresis and fail-safe logic. The embedded level controller can lower cost by replacing external control hardware. This non-contact liquid level sensor is ideally suited for corrosive, sticky or dirty liquids, and is widely selected for day tank, skid, IBC, sump and process tank level applications.
-
-
Specifications
- Range: 18.0' (5.5m)
- Accuracy: ± 0.2% of range
- Resolution: 0.079” (2mm)
- Dead band: 8” (20cm)
- Beam width: 3” (7.6cm)
- Configuration: WebCal® PC Windows® USB 2.0
- Memory: Non-volatile
- Supply voltage: 24 VDC (loop)
- Consumption: 0.5W
- Loop resist.: 400Ω max
- Signal output: 4-20 mA, two-wire
- Signal invert: 4-20 mA or 20-4 mA
- Signal fail-safe: 4 mA, 20 mA, 21 mA,22 mA or hold last
- Contact type: (4) SPST relays
- Contact rating: 60 VA, 1A maximum
- Contact fail-safe
- Power loss: Hold last
- Echo loss: Open, closeor hold last
- Hysteresis: Selectable
- Process temp.: F: 20° to 140° (C: -7° to 60°)
- Temp. comp.: Automatic
- Ambient temp.: F: -31° to 140° (C: -35° to 60°)
- Pressure: MWP = 30 PSI (2 bar)
- Enclosure rating: Type 6P, encapsulated,corrosion resistant & submersible
- Encl. material: Polycarbonate
- Trans. material: PVDF
- Cable jacket mat: Polyurethane
- Cable type: 9-conductor, shielded
- Cable length: 48” (1.2m)
- Process mount: 1” NPT (1” G)
- Mount gasket: Viton®
- Classification: General purpose
- Compliance: CE, RoHS
- Approvals: cFMus
-
Features
- Switch and control functions with continuous level measurement output up to 18.0’ (5.5m)
- Configuration is fast and easy via WebCal software and USB adapter
- Narrow 3” beam width and short 8” dead band optimized for small tanks\
- Four (4) programmable relays rated @ 1A / 60VA for switch, pump or valve control and fail-safety
- 1 pump or valve with 3 alarms
- 2 pumps (lead-lag) with 2 alarms
- 2 pumps (duplexing) with 2 alarms
- 4 independent switch point alarms
- PVDF transducer and 6P polycarbon ate enclosure for corrosive liquids
- Automatic temperature compensation for accurate measurement
