Application
-
The general purpose ultrasonic level transmitter provides continuous level measurement up to 49.2” (1.25m) with a 4-20 mA signal output, and is configured via our free WebCal software. This non-contact liquid level sensor is ideally suited for corrosive, sticky or dirty liquids, and is broadly selected for small day tank, skid, IBC, sump and process tank level applications.
-
-
Specifications
- Range: 49.2” (1.25m)
- Accuracy: 0.125” (3mm)
- Resolution: 0.019” (0.5mm)
- Dead band: 2” (5cm)
- Beam width: 2” (5cm)
- Configuration: WebCal® PC, Windows® USB 2.0
- Memory: Non-volatile
- Supply voltage: 24 VDC (loop)
- Consumption: 0.5W
- Loop resist.: 400Ω max
- Signal output: 4-20 mA, two-wire
- Signal invert: 4-20 mA or 20-4 mA
- Signal fail-safe: 4 mA, 20 mA, 21 mA, 22 mA or hold last
- Process temp.: F: 20° to 140° (C: -7° to 60°)
- Temp. comp.: Automatic
- Ambient temp.: F: -31° to 140° (C: -35° to 60°)
- Pressure: MWP = 30 PSI (2 bar)
- Enclosure rating: Type 6P, encapsulated, corrosion resistant & submersible
- Encl. material: Polycarbonate
- Strain relief mat.: Santoprene
- Trans. material: PVDF
- Cable jacket mat: Polyurethane
- Cable type: 4-conductor, shielded
- Cable length: 48” (1.2m)
- Process mount: 1” NPT (1” G)
- Mount gasket: Viton®
- Classification: General purpose
- Compliance: CE, RoHS
- Approvals: cFMus
-
Features
- Continuous non-contact level measurement up to 49.2” (1.25m)
- 4-20 mA output for longer signal distances up to 1000’ (300m)
- Configuration is fast and easy via WebCal software and USB adapter
- Narrow 2” beam width and short 2” dead band optimized for small tanks
- PVDF transducer and 6P polycarbonate enclosure for corrosive liquids
- Automatic temperature compensation for accurate measurement
