Application
-
The general purpose float leak switch provides reliable leak detection in and around secondary containment sumps and tanks with a 1A relay output. The flat body Valox leak sensor is ideal for placement in hard to reach interstitial areas with limited space. In the event of a leak, the foam polypropylene float will rise to signal the presence of unwanted liquid in the containment vessel. The leak detection switch is typically mounted flat on the bottom of the sump floor or secondary containment tank wall.
-
-
Specifications
- Orientation: Horizontal
- Contact type: (1) SPST reed
- Contact rating: 30 watts 240 VAC (0.14A resistive) 120 VAC (0.28A resistive) 120 VDC (0.07A resistive) 24 VDC (0.28A resistive)
- Contact output: NC (opens on rise)
- Process temp.: F: -40° to 221° (C: -40° to 105°)
- Pressure: 50 psi (3.4 bar)
- Sensor rating: NEMA 6 (IP68)
- Float material: Foamed polypropylene
- Body material: Valox 420
- Pivot pin mat.: Stainless steel
- Wire type: 2 conductor, #22 AWG
- Wire length: 10' (3m)
- Wire jacket mat: Halar jacketed
- Classification: General purpose
- Compliance: CE
- Approvals: UL
-
Features
- Valox sensor body with PP float and Halar® jacketed cable for corrosive liquids
- Flat, low profile sensor with minimal float rise for applications with limited space
- Dry contact, normally closed reed switch opens to signal the presence of liquid
