Pushbutton Encl - 3 PB x 22.5mm - Steel/

#453 in Electrical Pushbutton Enclosures

Height:	7.70
Width:	3.03
Length:	3.85

Please note - standard factory leadtimes may have been effected globally by the complications of Covid-19. Please contact us to confirm.
MPB3
Description: Pushbutton Encl - 3 PB x 22.5mm - Steel/
Extended Description: Pushbutton Encl - 3 PB x 22.5mm - Steel/Gray
Alternate Codes: 00623980403052,062398040305,62398040305
UPC: 623980403052
UNSPSC : 39121326-4478

Standard Lead Time:

Manufacturer: Hammond Manufacturing Co Inc

Brand: Hammond Mfg.

Packaging: EA

Your Price: $81.76

Quantity:

This product is not in stock - please contact us to confirm lead-time or place an order
Ask question about this product

Application: Designed to accept 22mm miniature oil tight pushbuttons, switches and pilot lights. Provides protection from dirt, dust, oil and water.

Special Features: Formed 14 gauge steel except the MPB1 which is 16 gauge. Smooth continuously welded seams. Welded brackets provide for enclosure mounting. Captive cover screws thread into sealed wells. Larger enclosures provide internally hinged removable covers, designed to hold the cover open during wiring (see table). Oil resistant gasket and adhesive. A bonding stud is provided on the door and a grounding stud is provided on the enclosure.

Standards: CSA, UL, CE

Part Information
- Part Number: MPB3
- Short Description: MINI PUSHBUTTON BOX
- Long Description: Pushbutton Encl - 3 PB x 22.5mm - Steel/Gray
- UPC: 62398040305
- EDP#: 40305
Series Information
- Series Name: N/A
- Series Number: MPB
Specifications
- Height: 7
- Width: 2.75
- Depth: 3.5
- Weight (lbs): 2.88
Available Documentation
- PDF: yes
- DXF: yes
- STEP: yes
Part Links
- E6 Catalog Page #: 252
- Product Page
Series Links
